7. Strap Preparation for the Buttresses
a. Gentlyattenanykinksorbendsoutofthestraps(key8).
b. Laythestrapacrossthelevelledarea
forthepoolasshownindiagram30.
Centrethestrapoverthepatiostone
asshownindiagram30.
Spacetheendofthestrap
2-1/4"(6cm)fromtheoutsideedge
ofthepatiostone.
c. Fastenonediagonalbracket(key4)
tothestrap(key8)usingfour3/4"
longbolts(key21)andnuts(key
10).Makesuretheangledpartofthe
bracketisfacingthecorrectdirection
asshownindiagram32.Thesurface
thatthediagonalbracketisfastenedto
willbethetopofthestrap.
d. Repeatsteps(a)to(c)fortheother
endofthestrap.
e. Repeatsteps(a)to(d)fortheother
straps.
30
32
8
21
10
4
31
