8. Installing the Upright
a.Usingastraightedge(youcanuseone
oftheholddownplates),dragalong
thetopedgeofthestraptoensurethe
groundisexactlyevenandlevelwith
thestrap(thearea24"(61cm)beyond
eachsideofthestrapmustbelevel
too).Ifitisnotlevel,spreadsome
crushedlimestone(orequivalent)on
theground.Standonthestrapand
tampitdownhardwithatamping
tool.Verifythegroundisleveltothe
strapbyrunningthestraightedge
alongthetopedgeofthestrap.Repeat
thisstepuntilthegroundislevel.
b. Gentlyliftthestrapandinsertfour
3/4"longbolts(key21)intothe
holesclosesttothecentreofthepool.
Ensuretheboltheadsarefacingthe
ground.Laythestrapbackdownon
thegroundandplacetheholddown
plateandbaseplate(asshownin
diagram36)overtheboltsprotruding
fromthestrapandfastenthenutsto
theboltsandtighten.
33
34
35
36
21
