Pool Warehouse SUNRAY - Install the Diagonals

No Diving or Jumping. Observe all Safety Rules.
1-20
2
10
42
39 40 41
2
26
4
1
1
1
21
10
37
Caution:
Failuretoproperly
installandtightenallof
theboltsandnutsmay
voidthewarrantyon
yourpool.
38
c. Fastenoneupright(key1)tothebase
plateusingthree3/4"longbolts(key
21)andnuts(key10).Makesurethe
bottomendoftheuprightisfastened
tothebaseplate.Thebottomend
oftheuprighthasthreelargeholes
whichareusedtofastentothebase
plate.
d. Whenyoucometosection2,youwillinstallthebottomrails,
linkingthemtothebuttresses.Makesurenowthatthereis
approximatelya1/16"(2mm)gapunderthetabatthebottom
ofeachuprightsothebottomrailsslideoneasily.
e. Repeatsteps(a)to(d)fortheothersideofthepool.
9. Install the Diagonals
a. Holdone
diagonalbrace
(key2)ap-
proximately
horizontal,
insertthefour
tabsattheend
 ofthediagonalintotheslotsinthe
upright(key1)(seediagram39).
b. Pullupwardontheinsertedendof
thediagonaltomakethetabsslideup
andlockintopositionintheslots.At
thesametime,swingtheotherendof
thediagonaldownontothediagonal
bracket(key4)onthebasechannel
(seediagrams40and41).
Important:
Ensureallfourtabsat
theendofthediagonal
areinsertedintothe
slotsintheupright.
