Veryimportant:asyouswingthediagonaldown,makesureyouapplyconstantupward
pressureontheendofthediagonalbracewiththetabstoensuretheystayfullylocked
inpositionintheslots.
c. Fastenthebottomendofthediagonalbracetothediagonalbracket(key4)withtwo
2-1/4"(57mm)bolts(key26)andnuts(key10).Donotovertightenthebolts.They
onlyneedtobesnugenoughtoensureasecuret(seediagram42).
d. Repeatsteps(a)to(c)fortheothersideofthepool.
e. Repeatsteps(7)to(9)fortherestofthebuttresses.
10.ButtressLocationVerication
a. Tiestringsbetweenstakes(D)and(E)andbetween(F)and(G).Thesewillbeused
asareferencetomakesurethebuttressesareexactlylinedupwitheachother.Stand
ateachcornerofthepoolandcheckthealignmentofthebuttresseswiththestrings.
b. JumptoSection2andcompletesteps
1(a)and(b).Thiswillallowyouto
installthebottombuttressrails,ensur-
ingthecorrectdistancebetweenthe
buttresses.Important:completeonly
steps1(a)to(c)fornow,andthen
continuewithstep11below;youwill
completetherestofSection2later.
11. Fill in the Hold Down Plates
a. Standingontheholddownplate,in-
sertmaterialintoallopenvoidsonthe
outsideedgesoftheholddownplates
untiltheyarefull.Thesevoidsarethe
openareasbetweenthegroundand
thetopedgesoftheholddownplate.
Thiswillpreventanylowspotsfrom
formingaroundtheholddownplates
whenthepoolislledwithwater.
43
Important:
Aftertheendsofthe
holddownplatehas
beenlledwithmate-
rial,placeasheetof
plastic(approximately
15"x15"(38cmx
38cm))ateachendof
theholddownplate.
Thiswillpreventany
additionalmaterialfrom
owingintotheendsof
theholddownplatethat
maycauselowspotsto
formaroundtheplates.
