No Diving or Jumping. Observe all Safety Rules.
1-24
23'-8"
. 11'-3 3/4"
12'-5"
11'-8"
7'-2"
9'-10"
1
4
'
-
5
"
.
.
1
4
'
-
5
"
12'-0" R6'-2"
3'-10"
Gap in the straight side between
Bottom Rails in the Vertical
Clips is 4"
STRAIGHT SIDE
- Upper Rail
8" X 9'R X 2 Places
DO NOT measure rail like this
STRAIGHT SIDE
- Bottom Rail
44 5/8" X 12'R X 4 Places
- Upper Rail
42 1/8" X 12'R X 4 Places
Strap3'-11"(2 Places)
TRANSITION A
- Bottom Rail
44 5/8" X 9'R X 4 Places
- Upper Rail
45 5/8" X 9'R X 4 Places
Gap in the end side between
Bottom Rails in the Base Plate
is 0.329"
measure rail like this
END SIDE
- Bottom Rail
44 5/8" X 6'R X 8 Places
- Upper Rail
45 1/2" X 5'6"R X 8 Places
NLR-1440335
NLR-1320143
NLR-1320 164
NLR-1440335
NLR-13201 43
NLR-132016 4
NLR-1320143
NLR-1440335
NLR-1320 164
NLR-1440335
NLR-1440335
NLR-1320143
NLR-1440335
NLR-13201 43
NLR-1320143
NLR-1320 164
NLR-132016 4
NLR-1510139
NLR-1510139
Notes:
1. Perimeter of the wall is 739"
2. Length of the wall is 740"
3. All dimensions are in inches unless otherwise specified.
4. All dimensions are referenced from the wall location.
5. Manufacturers tolerances and field condition may result
in dimensional variations.
4'-0"
NLR-1510139
NLR-1510139
NLR-1510139
NLR-1510139
ATLANTIC
12 x 24 Footprint
