No Diving or Jumping. Observe all Safety Rules.
1-5
PARTS LISTING - CONTENT LIST
Product Description: Sunray Oval Revised: Sept 2012
Product Code: PV2299XXXX
Quantity required for inst allation (by pool size)
INDEX # DESCRIPTION PARTS# LENGTH 1218 1224 1524 1530 1833
7 Top ledge TL10008
56 1/ 4"
6
TL10013
63"
4
TL10015
50 1/ 2"
4
TL10014
44 3/ 4"
4 2
TL10016
57 3/ 8"
4 4 4
TL10009
57 3/ 8"
8 8
TL10017
56 1/ 4"
4 4
TL10010
56"
6
TL10012
56 1/ 8"
4
1 Upright UR10008
47-1/ 2''
8 8 10 10 12
15 Ledge cover - resin (for buttress) LC10010 2 6 4 6 6
4 Ledge cover - steel (round end) LC10009 8 8 10 10 12
14 SideTop Plate - buttress 1320168 2 6 4 6 6
2 Bot tom connector/ Bott om Plate 1320103 8 8 10 10 12
Slotted Tube Connector (steel) 1470108 8 8 10 10 12
Slotted Tube Connector - side (resin) 1470087 2 6 4 6 6
47" Round Coping 1382480 13 16 17 20 23
19 Bot tom Rail Support 1490494 4 2 4 4
6 Slotted Tube 18' (blue) 1470127
62"
4
Slotted Tube 12' 1470126
55 1/ 2"
6 6
Slotted Tube 15' 1470097
55 1/ 2"
8 8
Slotted Tube 18' 1470098
55 1/ 4"
6
Slotted Tube 18' (black) 1470129
50"
4
Slotted Tube 24' (whit e) 1470105
44 1/ 8"
4 2
Slotted Tube 24' (green) 1470100
55 1/ 2"
4 8 12
8 Bot tom Rail 18' (blue) 1460134
61"
4
Bot tom Rail 12' 1460061
53 15/ 16"
6 6
Bot tom Rail 18' (black) 1460135
48 3/ 4"
4
Bot tom Rail 15' 1460062
53-15/ 16"
8 8
Bot tom Rail 18' 1460063
53 13/ 16
6
Bot tom Rail 24' (yellow) 1460064
54 1/ 16"
4
Bot tom Rail 24' (green) 1255624
55 7/ 8"
4 4
Bot tom Rail 24' (green) 1460136
55 1/ 8"
4 4 4
Bot tom Rail 24' (whit e) 1254424
44-5/ 8"
4 2
3 Hardware Pack (Qty. - 59) 1184312 1 1 1 1 1
Hardware Pack (Qty. - 29) 1184298 1 1 1 1 1
9 Upright CL10006
47-1/ 2"
2 6 4 6 6
10 Diagonal CL10007 2 6 4 6 6
13 Hold Down Plate 1320162 2 6 4 6 6
12 Diagonal Bracket 1320152 2 6 4 6 6
11 Oval bot t om Plate 1320154 2 6 4 6 6
16 to 20 Hardware Pack 1184292 1 3 2 3 3
20 12 St rap 1510132
215.55"
1 3
15' Strap 1510133
251.55"
2 3
18' Strap 1510134
287.55"
3
Wall 1 1 1 1 1
Wall Joiner Bar 11822 2 2 2 2 2
