Pooli SmartClean PR010989 - Filter Cleaning

8
4.3 FILTER CLEANING
4.3.1 Remove filter
Open the top cover : Put the robot aside the pool and open the top cover (Figure 4-1),
you have now access to the filter (4-2). Take out the filter basket (Figure 4-3).
4-1 4-2 4-3
4.3.2 Wash filter basket
4-4
4.3.3 Re-install filter
Re-install the filter basket in reverse steps.
Rinse the filter basket with clean water. Do not use a jet too
powerful (4-4).
