Parts reference table
N° Name Quantity N° Name Quantity
1 Cover with 6-way
valve
1 16 Prelter sealing joint 1
2 Sealing joint 3 17 Prelter plug 1
3 Sealing plug 1 18 32/38 connectors 1
4 Pressure gauge 1 19 38 sealing joint 3
5 Pressure gauge seal-
ling joint
1 20 32 sealing joint 2
6 M8 screw 1 21 32-50 hose clamp 2
7 Washer 1 22 Φ38 corrugated pipe 1
8 Central tube protec-
tion cap
1 23 Upper cover sealing joint 1
9 Central connection
tube
6 24 Clamp ring 1
10 Strainer 1 25 M8 nut 1
11 Safety pin 1 26 Suction prelter 2
12 Drain plug 1 27 25-42 hose clamp 4
13 Drain plug joint 1 28 Φ32 connection pipe to
the swimming pool
2
14 Electric pump + ltra-
tion shell group
1
15 Pump prelter 1
