Minor Repairs 321
Fuse assignment – fuse box in engine compartment
Notes
f Use the plastic grippers from the fuse boxes in the dashboard to replace the fuses.
Fuse numbers that are not listed in the table are not assigned in the fuse box.
Cayenne
No.
Cayenne S/
Cayenne GTS
No.
Designation Rating in A
1 1 Fan 60
22Fan 30
7 7 Ignition coils 15
8 - Ignition coils 15
- 8 Tank vent, air-conditioning compressor, intake pipe switchover, crankcase vent 15
9 - Engine control unit, high-pressure fuel injectors, throttle adjusting unit 20
- 9 Quantity control valve, camshaft adjuster, valve lift adjuster 15
10 -
Water run-on pump, tank leakage detection, carbon canister shut-off valve, fan, pressure sensor for air condi-
tioner
10
-10
Engine components: Cooling air output stages, carbon canister shut-off valve, pressure sensor for air condi-
tioner,tank leakage detection, exhaust flap control valve, Hall sensor, oil-level sensor
10
11 - Air-conditioning compressor, service interval sensor, crankcase vent 10
- 11 Engine control unit, high-pressure fuel injectors, throttle adjusting unit 20
12 - Camshaft adjustment, tank vent, quantity control valve, variable intake manifold 15
13 13 Fuel pump, right 15
14 14 Fuel pump, left 15
15 15 Engine control unit, main relay 10
17 17 Oxygen sensors ahead of catalytic converter 15
18 18 Oxygen sensors behind catalytic converter 7,5
