Drill a 7/16" hole here.
ROUTER HEIGHT ADJUSTER
TEMPLET
Remove this page from your manual and place it on your
router table so that the holes (1, 2, and 3) line up with the
holes in your table. Mark the place indicated. Drill a
7/16" hole at that point.
2
3
20
Table Top - Fence Side
1
