Fig. U
Fig. V
LUBRICATION
Ball bearings are grease packed at the factory and
require no further lubrication. Use a paste wax to
ensure smooth operation on all moving table parts. Do
not use any lubrication on the belt platen as this might
end up on the wheels, causing them to slip.
