20
PARTS LIST
4 IN. x 8 IN. (102 MM X 203 MM) BELT / DISC SANDER
PARTS LIST
ID Description Size Qty ID Description Size Qty ID Description Size Qty
X45E RUBBER FOOT 4 X43V DRIVE PULLEY 1 X42D TUBE CONNECTOR 1
X45D PHILIPS SCREW M4×10 16 X43U INNER HEX SCREW M8×12 2 X42C CAPACITOR SUPPORT1 1
X45C BOTTOM PLATE 1 X43T COLLECTOR SHAFT 1 X42B CAPACITOR 1 20µF300V 1
X45B PHILIPS SCREW (WHITE) M8×25 4 X43S PHILIPS SCREW M5×8 2 X42A INNER HEX SCREW M6×25 2
X45A LOCK WASHER (WHITE) D8 6 X43R FLAT WASHER D5 5 X429 CAPACITOR SUPPORT 2 1
X459 FLAT WASHER (WHITE) D8 6 X43Q WORK TABLE ANGLE POINT 1 X428 CAPACITOR 2 100µF125V 1
X458 BASE 1 X43P BELT FRAME CONNECT 1 X427 DISC PLATE 1
X457 CONNECT TUBE 1 X43N CORD BUSHING 1 X426 FLAT WASHER D4 7
X456 BIG PULLEY 1 X43M BELT COVER 1 X425 INNER HEX SCREW M5×8 1
X455 POLY-V- BELT 1 X43L PIN 2X10 1 X424 DUST BAG 1
X454 COLLECTOR BEARING 6000RZ 2 X43K SPRING WASHER 1 X423 POSITION SHAFT 1
X453 SPRING WASHER D26 1 X43H RIGHT COVER 1 X422 MITER GAUGE POINTER 1
X452 PHILIPS SCREW ST4.2×15 14 X43G LEFT COVER 1 X421 I TYPE HEX NUT M8 3
X451 FAN COVER 1 X43F SMALL PULLEY 1 X420 DUST BOX COVER 1
X450 FAN 1 X43E
PHILIPS SCREW & FLAT WASHER ASS’Y
M4×12 1 X41Z LOGO LABEL 1
X44Z BIG WASHER D5 4 X43D BELT EXHAUST COVER 1 X41Y WARNING LABEL 1
X44Y STANDARD SPRING WASHER D5 4 X43C
COLLECTOR MOUNTING SHAFT
2 X41X WARNING LABEL 2 1
X44X PHILIPS SCREW M5×16 2 X43B INNER HEX SCREW M5×20 3 X41W SCALE LABEL LEFT 1
X44W FAN HOUSING 1 X43A BELT MOUNTING PLATE 1 X41V SCALE LABEL RIGHT 1
X44V PHILIPS SCREW M5×10 12 X439 END CAP 1 X41U ROTATION LABEL 2
X44U FRONT COVER 1 X438 POWER CORD 1 X41T BELT TENSION LABEL 1
X44T DUST STORAGE BOX 1 X437 STRAIN RELIEF 1 X4C3 INNER HEX WRENCH 5 MM 1
X44S PHILIPS SCREW(WHITE) M5×8 1 X436 WIRE BOX COVER 1 X4C2 SCALE LABEL 1
X44R EXHAUST COVER 1 X435 PHILIPS SCREW ST4.2×28 1 X4C1 SPRING WASHER D40 1
X44Q DUST EXHAUST 1 X434 RELAY 1 X4C0
STANDARD SPRING WASHER
D4 5
X44P I TYPE HEX NUT M6 2 X433 WIRE BOX COVER 1 X4CD
TENSION HANDLE ASSEMBLY
1
X44N BAG CLAMP 1 X432 LEFT END CAP 1 X4CC
MITER GAUGE ANGLE LABEL
1
X44M CLAMP HANDLE 1 X431 KEY 5X5X15 1 X4CB POSITIONING PLATE 1
X44L SCREW M6×40 1 X430 WASHER 1 X4CA FLAT WASHER 2
X44K TOOTH LOCK WASHER D5 2 X42Z PHILIPS SCREW M6×16 left 1 X4BZ TOOTH LOCK WASHER D4 1
X44H SLEEVE 1 X42Y DISC PAPER 1 X4BY BEARING BUSHING 1
X44E PIN 5×10 1 X42X DISC COVER 1 X4BX SPRING PIN 4X22 1
X44D PHILIPS SCREW M5×25 2 X42W PHILIPS SCREW M4×10 6 X4BW
STANDARD SPRING WASHER
D6 8
X44C BELT TRACKING KNOB 1 X42V ANGLE POINTER 2 X4BV DISC WORK TABLE KNOB 1
X44B FLAT WASHER D6 4 X42U DISC LEFT SUPPORT 1 X4BU INNER HEX SCREW M5×12 1
X44A RUBBER WASHER 1 X42T HANDLE ASSEMBLY 2 X4BT PHILIPS SCREW M4×10 1
X449 ADJUST SPRING 1 X42S DISC WORK TABLE 1 X4BS
STANDARD SPRING WASHER
D5 6
X448 BELT FRAME/PLATEN 1 X42R MITER GAUGE BAR 1 X4BR PHILIPS SCREW M5×10 8
X447 TENSION SPRING 1 X42Q MITER GAUGE 1 X4BQ FLAT WASHER (WHITE) D5 5
X446 SLEEVE 2 X42P DISC RIGHT SUPPORT 1 X4BP LOCK WASHER (WHITE) D4 1
X445 SPRING WASHER D12 2 X42N BEARING 6203RZ 2 X4BN FLAT WASHER (WHITE) D4 1
X444 BEARING 6001RZ 2 X42M ROTOR 1 X4BM BAG CLAMP ASSEMBLY 1
X443 IDLER SHAFT 1 X42L PHILIPS SCREW M5×180 4 X4BL IDLER PULLEY ASSEMBLY 1
X442 IDLER PULLEY 1 X42K STATOR 1 X4BK
BELT WORKING TABLE ASSEMBLY
1
X441 BELT TENSION ASSEMBLY 1 X42J I TYPE HEX NUT M5 5 X4BJ
DISC LEFT SUPPORT ASSEMBLY
1
X440 INNER HEX SCREW M6×12 8 X42H MOTOR COVER 1 X4BH
DISC RIGHT SUPPORT ASSEMBLY
1
X43Y BIG WASHER D6 3 X42G SWITCH COVER 1 X4BG MITER GAUGE ASSEMBLY 1
X43X MITER GAUGE KNOB 1 X42F PHILIPS SCREW M3×10 2 X4BF INSTRUCTION MANUAL 1
X43W SANDING BELT 1 X42E SWITCH 1
