10
Drill may stall (if overloaded or improperly used) causing a twist. Always
expect the stall. Grip the drill firmly to control the twisting action and prevent loss of
control which could cause personal injury. If a stall does occur, release the trigger
immediately and determine the reason for the stall before re-starting.
INSTALLING AND REMOVING THE BATTERY PACK FROM THE TOOL
Make certain the lock-off button is engaged to prevent switch actuation
before removing or installing battery.
TO INSTALL BATTERY PACK: Insert battery pack into tool as shown in figure C.
TO REMOVE BATTERY PACK: Depress the battery release button as shown in figure D
and pull battery pack out of tool.
OPERATING INSTRUCTIONS
TRIGGER SWITCH & FORWARD/REVERSE BUTTON - FIGURE E
The drill is turned ON and OFF by pulling and releasing the trigger switch (1) shown in
figure E. The farther the trigger is depressed, the higher the speed of the drill. A
forward/reverse control button (2) determines the direction of the tool and also serves as
a lock off button. To select forward rotation, release the trigger switch and depress the
forward/reverse control button. To select reverse, depress the forward/reverse control
button in the opposite direction. The center position of the control button locks the tool in
the off position. When changing the position of the control button, be sure the trigger is
released.
LED WORK LIGHT
When drill is activated by pulling the trigger switch (1), the integrated LED work light (9)
will automatically illuminate the work area.
ADJUSTING TORQUE CONTROL - FIGURE F
This tool is fitted with a torque adjustment collar (3) to select the operating mode and to
set the torque for tightening screws. Large screws and hard workpiece materials require
a higher torque setting than small screws and soft workpiece materials.
• For drilling in wood, metal and plastics, set the collar to the drilling position symbol
• For screwdriving, set the collar to the desired setting. If you do not yet know the
appropriate setting, proceed as follows:
• Set the collar to the lowest torque setting.
• Tighten the first screw.
• If the clutch ratchets before the desired result is achieved, increase the collar setting
and continue tightening the screw. Repeat until you reach the correct setting. Use this
setting for the remaining screws.
DUAL RANGE GEARING - FIGURE G
The dual range feature of your drill allows you to shift gears for greater versatility. To
select low speed, high torque setting (position 1), turn tool off and permit to stop. Slide
gear shifter button (4) away from the chuck. To select the high speed, low torque setting
(position 2), turn tool off and permit to stop. Slide gear shifter button towards the chuck.
NOTE: Do not change gears when tool is running. If you are having trouble changing
gears, make sure that the dual range gear button is either completely pushed forward or
completely pushed back.
KEYLESS CHUCK - FIGURE H
To insert a drill bit or other accessory:
1. Grasp the chuck (5) and rotate it in the counterclockwise direction, as viewed from
the chuck end.
2. Insert the bit or other accessory fully into the chuck, and tighten securely by
rotating the chuck in the clockwise direction as viewed from the chuck end.
Do not attempt to tighten drill bits (or any other accessory) by gripping
the front part of the chuck and turning the tool on. Damage to the chuck and personal
injury may occur when changing accessories.
