5 volts (10 volts for 230 volts) at 150% of rated amperes.
If an extension cord is to be used outdoors it must be marked with the
suffix W-A or W following the cord type designation. For example – SJTW-
A to indicate it is acceptable for outdoor use.
RECOMMENDED EXTENSION CORD SIZES FOR USE WITH PORTABLE ELECTRIC TOOLS
Length of Cord in Feet
115V 25 Ft. 50 Ft. 100 Ft. 150 Ft. 200 Ft. 250 Ft. 300 Ft. 400 Ft. 500 Ft.
230V 50 Ft. 100 Ft. 200 Ft. 300 Ft. 400 Ft. 500 Ft. 600 Ft. 800 Ft. 1000 Ft.
0-2 18 18 18 16 16 14 14 12 12
2-3 18 18 16 14 14 12 12 10 10
3-4 18 18 16 14 12 12 10 10 8
4-5 18 18 14 12 12 10 10 8 8
5-6 18 16 14 12 10 10 8 8 6
6-8 18 16 12 10 10 8 6 6 6
8-10 18 14 12 10 8 8 6 6 4
10-12 16 14 10 8 8 6 6 4 4
12-14 16 12 10 8 6 6 6 4 2
14-16 16 12 10 8 6 6 4 4 2
16-18 14 12 8 8 6 4 4 2 2
18-20 14 12 8 6 6 4 4 2 2
Nameplate Ampere Rating
FOREWORD
MODEL 7539 Porter-Cable Router incorporates a speed control that
provides operating speeds from 10,000 RPM to 21,000 RPM to handle the
most demanding router applications in various materials.
MODEL 7538 Porter-Cable Router is designed for continuous, rugged
operations to handle the most demanding routing applications. The
operating controls are shown in Fig. 1 and Fig. 2.
FUNCTIONAL DESCRIPTION
7
NOTES
