8
1. Plug in transformer (K) to 120-volt AC,
60-hertz outlet. Note: Bulb in landscape light
must be 12-volt AC.
2. Adjust timer control as desired.
OFF: Power off. Fixture will not light.
ON: Power on. Fixture will stay lit continuously.
AUTO: Fixture will light automatically as
surrounding area gets dark.
4H: Fixture will light automatically as surrounding
area gets dark. After 4 hours, the fixture will
automatically turn off.
6H: Same as above, After 6 hours, the fixture will
automatically turn off.
8H: Same as above, After 8 hours, the fixture will
automatically turn off.
Time Rotary Control Switch
TRANSFORMER OPERATION INSTRUCTIONS
1
2
1
1
K
To Next Page
