4. Check circuits breaker if the bulb from
the landscape light did not light.
Total bulb wattage connecting to
transformer (K) can't exceed 120 volts.
Circuits Breaker
Photo Sensor
Time Rotary
Control Switch
Input Power Cord
Input Cord
Attach
Output
Cable
1
3
1
4
3. If the circuit on transformer (K) overloads,
it will automatically power down to protect
itself. Press circuit breaker button to
restart transformer (K).
9
K
TRANSFORMER OPERATION INSTRUCTIONS
