PRK-7000 Operation Manual
-
4
-
① Power switch
Switch for turning power ON and OFF.
② USB
USB connector for other instruments.
③ RS-232
RS-232 connector for other instruments.
④ Video Output
Connector for the VGA monitor cable
⑤ Power supply connector
Connector for the power supply cable.
⑥ Forehead Rest rubber
Place the examinee’s forehead against this rest.
⑦ Measurement window
Window for the examinee to look into for measurement.
⑧ Chin Rest
Place the examinee’s chin on this rest
If you want to connect the input / output signal ports and other devices that must meet IEC standards
(IEC60950 IT equipment, IEC60601 medical equipment)
If in doubt should contact POTEC or your authorized distributor.
⑥
⑦
⑧
② ③ ①
④
⑤
