PRK-7000 Operation Manual
-
3
-
3 Description
3.1 Main Unit
⑦
①
②
③
④
⑥
⑧
⑤
⑦
①
①
②②
③③
④
⑥⑥
⑧⑧
⑤⑤
Name Function
① Measurement Head
Unit that performs measurement.
② Height Adjustment mark
Align the height of the examinee’s eye with this mark by adjusting
the height of chin rest.
③ Monitor Monitor that displays Measurement and SET Modes displays.
④ Chinrest Lever
Align the height of chin rest up and down.
⑤ Measuring button Press this button for measurement.
⑥ Operation Lever Use this lever for alignment and focusing.
⑦ Printer Print the measured result.
⑧ Stage Holding Lever Holds the movement of stage (sliding table).
To Next Page
