Assembling Your
Handheld Steam Cleaner
STEAM CLEANING ACCESSORIES
WARNING: Do not connect accessories while unit is emitting steam.
JET NOZZLE / EXTENSION HOSE / TRIANGLE BRUSH
1. Select one of the four accessories (Jet Nozzle shown as example) and push onto the Steam
Nozzle (A).
2. Rotate accessory until the yellow lock/release button snaps into the accessory hole (B).
NOTE: The Jet Nozzle and Triangle Brush can be connected to the end of an Extension
Hose for reaching high or difcult spots. Connect the Extension Hose, then connect
your desired accessory in the same way as you would normally connect to the Jet
Nozzle.
UTILITY BRUSHES / SCRUB PAD
NOTE: These accessories connect to the Jet Nozzle, not the
Steam Nozzle.
1. Firmly press accessory onto tip of Jet Nozzle. Press it on as far
as possible to prevent steam leakage (See gure 1).
2. To remove Utility Brush, simply grip it rmly and pull it off Jet
Nozzle.
FIGURE 1
A B
