STARTING A WARM ENGINE
1. Move ON/OFF switch to the ON position.
2. Move the choke lever to the HALF
CHOKE position.
3. Squeeze and hold the throttle trigger.
Keep throttle trigger fully squeezed until
the engine runs smoothly.
4. Pull starter rope sharply until engine runs,
but no more than 5 pulls.
5. Allow engine to run 15 seconds, then
move the choke lever to the OFF CHOKE
position.
NOTE: If engine has not started, pullstarter
rope 5 more pulls. If engine still does not run, it
is probably flooded.
STARTING A FLOODED ENGINE
Flooded engines can be started by placing
the choke lever in the OFF CHOKE position;
then, pull the rope to clear the engine of ex-
cess fuel. This could require pulling the starter
handle many times depending on how badly
the unit is flooded.
If the unit still doesn't start, refer to
TROUBLESHOOTING TABLE or call
1-800-554-6723.
OPERATING THE COUPLER
This model is equipped with a coupler which
enables optional attachments to be installed.
The optional attachments are:
MODEL:
Edger ....................... PP1000E
Cultivator ................... PP2000T
Blower ...................... PP3000B
Brushcutter ................. PP4000C
WARNING: Always stop unit and dis-
connect spark plug before removing or instal-
ling attachments.
REMOVING PRUNER ATTACHMENT
_3R OTHER OPTIONAL ATTACH-
ENTS)
CAUTION: When removing orinstalling at-
tachments, place the unit on a flat surface for
stability.
1. Loosen the coupler by turning the knob
counterclockwise.
Upper Tube
Coupler
Lower
Attachment
TIGHTEN Knob
2. Press and hold the locking/release bL_ton.
Locking/Release
Button
/
Lower Attachment
UpperTube
3. While securely holding the engine and
upper tube, pull the attachment straight
out of the coupler.
INSTALLING OPTIONAL ATTACH-
MENTS
1. Remove the tube cap from the attach-
ment (if present).
2. Position locking/release button of attach-
ment into guide recess of coupler.
3. Push the attachment into the coupler until
the locking/release button snaps into the
primary hole.
4. Before using the unit, tighten the knob se-
curely by turning clockwise.
Coupler Primary Hole
\ / Guide Recess
Upper Locking/ Attachment
Tube Release
Button
I=,WARNING: Make sere the locking/
release button is locked in the primary hole
and the knob is securely tightened before op-
erating the unit.
INSTALLING ATTACHMENT
HANGER
An attachment hanger is provided for storage
when attachment is not in use.
To install hanger on attachment:
1. Remove the tube cap from the attach-
ment (if present) and discard.
2. Press and hold the locking/release button.
3. Push hanger onto the attachment until the
locking/release button snaps into the hole.
OPERATING POSITION
HAeLaV_AYS_._,_ '_'_'_
Prot ionEye
I ant
[ _L/ Heavy Shoes ,,
Y
A
dll DANGER: Do not extend arms above
shoulders while pruning, Do not stand be-
neath branch being cut.
_WARNING: Always wear head, eye,
hearing, foot and body protection to reduce
the risk of injury when operating this unit.
