22
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
REPAIR PARTS SNOW THROWER - MODEL PR271 (96192009102)
AUGER HOUSING / IMPELLER ASSEMBLY
KEY PART
NO. NO. DESCRIPTION
1
2
05.09.006-C
1 532 42 11-35 AUGER 27 LH
2 532 42 11-23 AUGER 27 RH
1 581 70 83-73 AUGER HOUSING
2 532 40 77-27 SCRAPER BAR
3 872 27 05-05 CARRIAGE BOLT 5/16-18 X
.625 GR5
4 532 15 53-77 NUT 5/16-18
05.09.011-D
1
2
3
5X
4 5X
