POURSTEADY
©2019 — REV 4.0

INSTALLATION
Fd irulation tub to drain
8
• The smaller uninsulated, transluscent tubing
running from the Poursteady circulates a small
amount of water running to the top of the machine,
maintaining the water temperature even if it has
not been used recently.
• Run this tube to the drain alongside the drain-tube
itself.
• Cut to length (if desired).
• Insert the loose end into the drain and secure.
onnt hot-atr uppl tub
to Maro boilr
7
• The hot water supply tube and black insulation
connected to the Poursteady (see below) should pass
through the slot in the counter.
• Bring the loose end of the tubing and insulation to
the barbed OUT tting on the top of the Marco and
cut to length (if desired).
• Carefully work the plastic tube over the barbed-
tting until secure.
SCALE 1 : 4
SCALE 1 : 3
