ENGLISH
INSTRUCTION MANUAL
Introduction
To get the most out of your new garden shredder,
please read these instructions and the enclosed
safetyinstructions before use. Please keep the
instructions in a safe place in case you need to
refer to them later.
Technical specifications
Engine type: 4-stroke single-cylinder engine
Power rating: 6.5 HP/196 cm3
Working speed: 2,000 rpm
Starting method: Recoil starting
Fuel: 95 octane unleaded petrol
Engine oil: ordinary engine oil (SAE 10W30/
SAE 10W40) must be added
before first use
Tank capacity, fuel: 2 l
Tank capacity, engine oil: 0.6 l
Shredding/chipping capacity: max. 76 mm dia.
Main components
1. Screen for discharge chute
2. Discharge chute
3. Wing nut
4. Foot
5. Wheels
6. Feed chute for chipping
7. Feed nozzle for chipping
8. Transport handle
9. Hopper for composting
10. On-off switch
11. Fuel tank
12. Fuel cap
13. Exhaust pipe
14. Air filter
15. Throttle lever
16. Choke lever
17. Recoil starter
18. Oil bung
19. Spark plug cover
20. Oil filler cap
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
18
19
20
17
