Power-Pole C-MONSTER User Manual

C-MONSTER TOP SIDE PROGRAMMING
INSTRUCTIONS
Need help? Contact our Technical Support Team at 1 + 813.689.9932 Option 2
©2017 all rights reserved. Power-Pole Shallow Water Anchor U.S. Patent No. 6,041,730
Top Side Control Switch Functions – HPU (Hydraulic Pump Unit)
1. Press and hold the PROGRAM button for 6 seconds until LED flashes
red and two chimes are heard followed by a single beep. (FIG. 1)
 NOTE: You are now in Function 1.
2. Press the PROGRAM button to toggle through the remaining functions
below, until you reach the one you wish to adjust:
1 beep = Set HPU as single, port or starboard side (see Function 1)
2 beeps = Changes the speed of the standard key fob remote control (Figure 2)
3 beeps = Up direction sensitivity adjustment – Controls the operation
of the Auto Up features. If the unit continues to run once retracted,
increase the sensitivity. If the unit stops running prematurely, decrease
the sensitivity. (FIG. 2)
4 beeps = Down direction sensitivity adjustment – Controls the operation of the
Auto Down feature. If the unit turns off prematurely during deployment,
decrease the sensitivity. If the unit continuous to run once anchored, increase the sensitivity. (FIG. 2)
You can use the UP and DOWN buttons to change the settings, (NOTE: default settings are in the middle of the range).
Tone increases with level (1-10). (FIG. 2)
Highest tone level 10
9
8
7
6
Middle range tone level 5
4
3
2
Middle range tone level 1
Once you have made all desired setting changes, press and release the PROGRAM button to save your settings and exit
program mode. You will hear a series of beeps and the LED light will return to flashing green.
Programming
Button
Up Button
Down Button
Figure 1
Figure 2
Press UP for higher
speed setting /
higher sensitivity
Press DOWN
for Lower speed /
lower sensitivity
