23
3 9142960901 Rocker arm shaft 2 46 303100072 6205 bearing 1
4 9230960902 ROCKER ARM 2 47 9198960101 Oil filler gauge 1
5 303020444 Bolt M6X12 1 48 9158960901 CAM SHAFT 1
6 9142960902 Rocker shaft baffle 2 49 9564960901 Piston ring assembly 1
7 303020620 Bolt M8x60 4 50 9129960901 Piston 1
8 9051960902 Muffler tail pipe 2 51 9015960901 Connecting rod assembly 1
9 303020444 Bolt M6X12 1 52 9122960901 Crankshaft assy 1
10 9221960902 COVER 1 53 9438960901
Speed regulating gear
combination
1
11 9170960902 AIR FILTER cover 1 54 9140960103 Locating pin φ8×14 2
12 9529960905 Air filter element 1 55 303043088 Flat gasket 1
13 9170960901 Air filter seat 1 55A 9245960906 Box gasket 1
13A 303030112 Self-locking nut M6 2 56 9563960901 Crankshaft box body 1
14 9051960905 Thickening bubble tube 1 57 9221960901 LOWER SHIELD 1
15 9532960901 Primer 1 58 9246960902 Oil seal 1
16 9533960202 Oil pipe clamp 2 59 9565960901 Catalytic igniter assembly 1
17 9568960901 Carburetor assembly 1 59A 303020490 Bolt 2
18 9245960102 Air filter gasket 2 60 9152960901 FLY WHEEL 1
19 9245960108
Carburetor and heat shield
gasket
1 61 9414960101 COOLING FAN 1
20 9535960901 Thermal baffle 1 62 9226960901 COOLING FAN COVER 1
21 9245960907
Cylinder head with heat
shield gasket
2 63 9194960501 Clutch Drum 1
22 303010394 Carburetor studs 2 64 303020511 Self-locking nut 1
23 9142960903 VALVE SPRING seat 2 65 9528960901 STARTER ASSY 1
24 9402960901 VALVE COTTER 2 66 303020671 Bolt 4
25 9113960901 INTAKE VAVLE 1 67 303020444 Bolt M6X12 4
26 9113960902 EXHAUST VAVLE 1 68 9013960902 THROTTLE LINKAGE 1
27 9013960901 PUSH ROD 2 69 9332960902 IDLE SPRING 1
28 9536960501 TAPPET 2 70 9230960101 Plunger arm 1
29 9140960102 DOWEL PIN 2 71 9332960901 Speed regulating spring 1
30 9146960901 CIRCLIP, PISTON PIN 2 72 9005960501 Throttle handle 1
31 9140960901 PISTON PIN 1 73 303043041 Flat gasket 1
32 9245960904 GASKET,CYLINDER HEAD 1 74 9534960101 Cotter 1
33 9228960901 Governor seat fixing plate 1 75 9226960913 Housing support 1
34 303020444 Bolt M6X12 2 76 303020444 Bolt M6X12 2
35 9566960301 Spark plug 1 77 303010108 Screw 3
36 9020960901 Cylinder head assembly 1 78 9529960903 TANK ASSY FUEL 1
37 303010394 Carburetor studs 2 79 9225960902 Gasoline engine housing 1
38 9245960905 Muffler gasket 1 80 303020246 Bolt M6x16 2
39 9569960901 Muffler assembly 1 81 9529960906 Fuel tank cap assembly 1
40 303030112 Self-locking nut M6 2 82 9051960906 Breather pipe 1
41 9440960902
Flameout switch
combination
1 83 303020246 Bolt M6x16 2
42 303020583 Bolt 2 84 9226960912 Fuel tank bracket 1
43 9246960901 Oil seal 1 85 9051960901 Oil tube 1
86 9115960901 Fuel filter strainer 1
