Engine parts list
Item Stock# Description Qty.
Ite
m
Stock# Description Qty.
1 100011264-0003 Bolt, M6×16 7 27 100030062 Motor Base 1
2 100056645 Valve Cover 1 28 100033258 Guide Clamp 1
3 100713739 Breather Hose 1 29 100052405 Spring 1
4 100010181
Gasket, Valve
1 30 100005137 Clamp 2
5 100004419
Rocker Arm
2 31 100017699
Fuel Hose
1
6 100050881 Rocker Arm Base 1 32 100005629 Gasket, Carburetor 1
7 100011260-0005 Bolt, M6×10 3 33 100098952 Air Filter Assembly 1
8 100007083 Shroud 1 34 100099680
Air Filter Base
1
9 100050896 Valve Locker 4 35 100005078 Air Filter Baffle 1
10 100073758 Valve Spring Seat 2 36 100004771 Air Filter Element 1
11 100713979 Valve Spring 2 37 100087055 Air Filter Cover 1
12 100004599 Intake Valve Seal 1 38 100004949 Bolt 1
13 100002464-0001 Bolt, M8×60 4 39 100011463-0002 Nut, M6 2
14 100079792 Cylinder Head 1 40 100155656 Gasket, Cylinder Head 1
15 100055588-0009 Bolt, M6×20 3 41 100010558 Pin, φ10×16 2
16 100010387 Stud, M8×34 2 42 100077152 Push Rod 2
17 100009376 Spark Plug 1 43 100004262 Tappet 2
18 100061091 Stud, M6×98 2 44 100713981 Exhaust Valve 1
19 100078607
Gasket,
Carburetor
1 45 100713980 Intake Vavle 1
20 100122101 Insulator 1 46 100003243 Piston Ring Set 1
21 100078606
Gasket,
1 47 100003221 Circlip 2
22 100127490 Carburetor 1 48 100003123 Piston Pin 1
23 100050035
Stepping Motor
1 49 100003086 Piston 1
24 100051029-0002 Screw, M4×6 4 50 100003446
Connecting Rod
1
25 100093486 Stepping Motor 1 51 100011319-0001 Bolt, M8×32 6
26 100010947-0001 Screw, M4×12 2 52 100128008 Crankcase Cover 1
