POWERBOR PB32 - Page 12

PB32 Original instructions Apr 2019
12
No.
Part
Description
Qty
1
W18XC202
M6×25 SOCKET CAP HEAD SCREW
1
2
RD23603
COOLANT BOTTLE ASSEMBLY
1
3
RD4414
SCREW M4 X 10
2
4
RD33338
FIXED RATCHET WHEEL
1
5
18Y3007
COOLANT BRACKET
1
6
W18XC209
SCREW
2
7
W18XC519/A
GLAND ( INCLUDED IN ITEM 41)
1
8
18Y180
PAFS13 CONDUIT
1
9
W18XC311/A
RETAINING BRACKET
1
10
W18XC502
PINION BUSH
2
11
W18XC313
PINION
1
12+13
W18Y175
HANDLE AND KNOB
3
14
W18XC224
M5 X18 GRUB SCREW ( INCLUDED IN ITEM 41)
6
15
W18XC219
M5 STEEL NUT ( INCLUDED IN ITEM 41)
6
16
W18XC525
PANEL SCREWS M3 X 10
8
17
18Y3017/CS
PANEL ASSEMBLY 110V
1
17
18Y3018/CS
PANEL ASSEMBLY 230V
1
18
W18XC312
BRASS GUIDE
2
19
W18XC322
RACK
1
20
W18XC304
SLIDE
1
21
W18XC201
SCREW
4
22
18Y3009
M6 X 8 SKT SCREW
1
23
18Y3004
ARBOR SUPPORT BRACKET
1
24
W18XC901/H
SWIVEL ELBOW
1
25
W18XC249
M5 X 10 SOCKET CAP HEAD SCREW
6
26
W18XC901/E
COOLANT RING COVER
2
27
W18XC901/F
O RING 24-30
2
28
W18XC309
FLANGED BUSH
1
29
W18XC223
M6 X 40 SOCKET CAP HEAD SCREW
2
30+31
W18Y130
ARBOR ASSEMBLY
1
32
18Y3000
GUARD SLIDE
1
33
RDA4201
M4 x 14 BUTTON HEAD SCREW
2
34
18Y3001
GUARD
1
35
RDA3032
GUARD SUPPORT
1
36
RD4347
M5 X 16 C/SNK SOCKET SCREW
2
37
W18XC214
M6 WASHER
2
38
W18XC212
M6 X 10 CAP HEAD SCREW
1
39
W18Y138
MAGNET ASSEMBLY
1
40
W18XC329
SHIM STRIP
1
41
W18Y138
HOUSING SUB-ASSEMBLY
1
