POWER BOX 40/24
- 3 -
1. - Set the channel select switch to “B”.
2. - Set the servo select switch to “reset”.
3. - Stick neutral, trim central, press + button, yellow and red light up.
4. - Stick right, press + button.
5. - Stick left, press + button.
6. - Set servo select switch to “save”, press + button, job done.
Both LEDs (red and yellow) shoul d now go out, confirming that the initialisation
process of this backer channel is also concluded.
Repeat the procedure with socket bank “C” and the associated transmitter
stick.
If you make a mistake, set the servo select switch to “reset” and press the + and -
buttons simultaneously. This resets the values for the channel concerned, and
you can re-start the set-up procedure for that channel.
Now you want to adjust the servos of one channel:
Select the appropriate socket bank on the Adjustor Board (A, B, C).
Select the servo to be adjusted using the servo select switch. The servo socket at
the outer edge of the PowerBox Champion is Servo “1”; the innermost servo of
the bank of four sockets is Servo “4”.
You can now adjust the centre, right and left servo end-points for that servo. To ad-
just the end-points you must hold the corresponding transmitter stick in the appro-
priate position.
You can now set the servo travels precisely using the + and - buttons. Note that it is
also possible to set non-symmetrical values. For coarse adjustments you can
hold the button pressed in, and the servo will move continuously in the desired di-
rection. For fine adjustments press the button briefly.
To reverse the servo move the transmitter stick to one end-point, then hold one but-
ton pressed in until the servo runs to the opposite end-point. This may take up to
30 seconds. This means that you can watch what is happening; after all, you don’t
have to reverse servos every day. Move the stick to the opposite end-point, then
hold the other button pressed in and allow the servo to run to the other
endpoint.
