x. After replacing Tip Seal Set, reassemble the FS set and fan duct (2) to the air end.
Tighten bolts and nuts temporarily and confirm if crankshaft rotates smoothly by hand
and tighten them firmly. Tightening torques are as below.
Tightening torque
First Second First Second
17 in-ib 175 in-lb 17 in-ib 265 in-lb
SLAE03E SLAE05E / SLAE05EHP
NOTE: Assemble so that dust seal and tip seal will not drop between Orbit (OS) scroll and FS scroll set.
