m CAUTION! RISK OF INJURY! Pay
attention to flying chippings and splinters.
There is the risk of injury.
Keep out of the reach of children. Store the
product out of the reach of children.
Check the product for damage before each
use. Please do not use this device if you find
that it is damaged in any way.
Check that the screws are tight before each
use.
Use the product on a solid, level and intact
surface (e.g. a workbench).
Always disconnect the drill from the power
supply before making adjustments or work
breaks.
The drill stand must be mounted on a
workbench or a stable, tilt-free table, to
ensure a safe work. Use the drill holes
5
in
the base plate
6
.
Assembly
Note: You need a 5 mm hexagon key
(provided), two open-ended spanners
(10 mm & 14 mm) and a slot screwdriver
(1.0 x 6.0 mm) for assembly and adjustment.
Connect the pillar
7
to the base
plate
6
and tighen the screw to fix the pillar
(see Fig.A).
Then fix the slider
9
on the pillar.
Mount the lever arm
2
onto the slider
(see Fig.B). Tighten the screws and nuts as
tight as possible.
Mount the vise
13
onto the base plate. To do
this connect the screws with the guide slots
4
in the base plate through the two long
slots
14
(see Fig.C).
Note: The vise can be positioned exactly by
moving the guide slots and long slots.
Mounting the work piece
Hold the quick-release button
16
pressed and
pull the locking device
15
back as far as it
goes (see Fig.D).
Place the work-piece into the vise
13
.
Press the quick-release button and push the
locking device with the clamping jaw
17
against the work-piece.
Tighten the work-piece by turning the locking
device
15
clockwise (see Fig.E).
Clamping in and adjusting the
drill
Fit the drill with its clamping collar into the
drill holding fixture
3
and tighten securely
(see Fig.F).
Insert a suitable drill bit into the chuck.
Unscrew bolt
12
(see Fig.G).
Move the slider
9
with the clamped in drill
on the pillar
7
, until the drill nearly touches
the work-piece.
Retighten screw securely.
Adjusting the drill depth
Loosen the block
8
and slide it up to the
slider
9
(see Fig.H).
Loosen the locking screw
10
by turning it to
the left (see Fig.H).
Make sure that the bolt
1
will be released
doing this and slides down to the lowest
position.
Move the lever arm
2
down and read off
the desired drill depth on the drill gauge with
indicator
11
.
Fix the locking screw
10
and block
8
with a
right turn (see Fig.I).
Do not overtighten the locking screw
10
after
the bolt
1
is fixed.
