Be careful to assemble all components in the
sequence they are presented.
Inch
MM
A. Attach Pivot Arm (F) to Main Frame (A) as shown using Small Shaft (15) and:
Two 27 (5/16” x 1/2” flat allen head bolt)
Two 30 (5/16” washer)
B. Tighten Allen Head Bolts (28) to keep Small Shaft (15) in place.
C. Attach Foot Plate (G) onto Pivot Arm (F) as shown using Shaft (16).
Tighten Allen Head Bolts (28) to keep Shaft (16) in place.
D. Attach End Cap (1) to Pivot Arm (F) as shown.
Attach two Rubber Pads (12) to Pivot Arm (F) as shown.
Attach Round End Caps (10) to Foot Plate (G).
NOTE:
Finger tighten all hardware in this step. Do NOT wrench tighten until the end
of step 7.
8
S T E P
