CHAPTER 7—DISPLAY OPERATION
INTRODUCTION
This chapter tells how to set up the power meter from the display only. You
can also set up the power meter using POWERLOGIC SMS-3000, SMS-1500,
or PMX-1500 software. Refer to the software instruction bulletin(s) for specific
instructions.
MODES
The power meter has the following modes. Each mode is detailed in
this section.
• Summary
• Power
• Energy
• Demand
➀
• Power Quality
➀
• Min/Max
➁
• Alarm Setup
➁
• Alarm Log
➁
• Setup
• Resets
• Diagnostics
➀ PM-620 and PM-650.
➁ PM-650 only.
