Bulletin No. 3020IM9503R6/98 Power Meter
December 1998 Appendix F—Register List
1998 Square D All Rights Reserved 85
Reg. No. ➀ Register Name Units Range
1092 C Voltage Volts/Scale 0 to 32,767
Fundamental Factor D
RMS Magnitude
1093 C Voltage 10ths of 0 to 3,599
Fundamental Degrees
Coincident Angle
1094 A-B Voltage Volts/Scale 0 to 32,767
Fundamental Factor D
RMS Magnitude
1095 A-B Voltage 10ths of 0 to 3,599
Fundamental Degrees
Coincident Angle
1096 B-C Voltage Volts/Scale 0 to 32,767
Fundamental Factor D
RMS Magnitude
1097 B-C Voltage 10ths of 0 to 3,599
Fundamental Degrees
Coincident Angle
1098 C-A Voltage Volts/Scale 0 to 32,767
Fundamental Factor D
RMS Magnitude
1099 C-A Voltage 10ths of 0 to 3,599
Fundamental Degrees
Coincident Angle
1200 ➁ Minimum Update Interval In 1000ths of a second 0 to 10,000
1201 ➁ Minimum Frequency Hertz/Scale Factor F 4500 to 6600
1202 ➁ Reserved
1203 ➁ Minimum Current, Phase A Amps/Scale Factor A 0 to 32,767
1204 ➁ Minimum Current, Phase B Amps/Scale Factor A 0 to 32,767
1205 ➁ Minimum Current, Phase C Amps/Scale Factor A 0 to 32,767
1206 ➁ Minimum Current Neutral, Calculated Amps/Scale Factor A 0 to 32,767
1207 ➁ Reserved
➀ These registers can be used with POWERLOGIC, Modbus, or Jbus protocols. Although POWERLOGIC
and Jbus protocols use a zero-based register addressing convention and Modbus uses a one-based
register addressing convention, the power meter, when configured for Modbus communications,
automatically compensates
for the Modbus offset of one. Regard all registers as holding registers where a
30,000 or 40,000 offset can be used (e.g., Current, Phase A = 31,003 or 41,003).
➁ PM-650 only.
