Powernail 50F - Operation

4
The Model 50F nails down fl ooring from
3/8” to 3/4” using the Powernail FLEX adjustable
foot assembly that can be adjusted to fi t diff erent
fl ooring profi les.
To use the Model 50F, properly position the tool
on the fl ooring plank (See picture below). Pull up
and hold the black safety trigger to activate the
orange fi ring trigger. The nailer will drive and set
the nail at the correct angle.
Note: Modifying or altering the nailer in anyway
can potentially cause injury and may void the
warranty.
The unique body design allows for diff erent grip
angles and has an adjustable exhaust port to
redirect nailer exhaust.
OPERATION
The Model 50F installs
tongue and groove
fl ooring from
3/8” to 3/4”
.
4
3/4”
19 mm
Exotics
5/8”
15 mm
1/2”
12 mm
3/8”
9 mm
