Oil Dipstick
14
Switch Key
12
Choke lever
15
Primer Bulb
13
Drain Plug
Auger Control Bar
The Auger Control Bar is used to engage and disengage the augers. Pull back the Auger Control Bar to
engage the augers; release to disengage the augers.
Chute Rotation Handle
To adjust snow discharge direction, rotate the handle clockwise or counter-clockwise.
Augers
When engaged, the augers rotate to cut snow and direct it into the auger housing to be discharged out the
chute.
Discharge Chute
The chute provides a discharge path for snow being thrown. The chute is adjustable.
Shave Plate
The Shave Plate maintains contact with pavement as the snow thrower is propelled, allowing snow close
to pavement's surface to be discharged.
11 12 13 14 15
