Powersmart DB7006 - ENGINE PARTS LIST; Engine Component Identification

21
Item Stock# Description Qty Item Stock# Description Qty
1 303020444
Hexagon Head Flange Bolt
M6X12
4 45 9129960701 Piston 1
2 9020960102 Breathing cover 1 46 9015960501 Connecting rod 1
3 9051960302 muffler pipe 1 47 9158960501 Camshaft assembly 1
4 9245960103 Cylinder Head Cover Gasket 1 48 303020508 Purge cock 1
5 303020382 Screw M6X12 2 49 303020518 Drain bolt 1
6 9143960101 Air lock nut 2 50 303043042 Aluminum washer 1
7 9143960102
Valve clearance adjusting
nut
2 51 3612552151 Bearing 1
8 9230960101 Valve rocker 2 52 9122960501 Crankshaft assembly 1
9 9142960101 Rocker seat locating bolt 2 53 9438960101
Speed regulating driven
gear combination
1
10 9220960101 Push rod guide plate 1 54 9121960101 Governing gear shaft 1
11 9170960102 Intake valve spring seat 1 55 3612552151 Bearing 1
12 9402960101 Exhaust valve adjusting cap 1 56 9140960103 Location pin 2
13 9170960103 Exhaust valve spring seat 1 56A 9245960106 Case gasket 1
14 9531960101 Valve spring 2 57 9563960702 Left crankcase cover 1
15 9245960101 Oil shield assembly 1 58 9569960705 Oil gauge assembly 1
16 303020620 Bolt M8X60 4 59 303020444
Hexagon Head Flange
Bolt M6X12
1
17 9020960101 Cylinder head assembly 1 60 303020509 Bolt M8X32 6
18 9566960301 Spark Plug 1 61 9246960101 Oil Seal 1
19 303010324 Muffler stud 2 62 9228960301
Governor seat fixing
plate
1
20 9245960105 Muffler gasket 1 62A1 9005960101 Throttle governor handle 1
21 9569960701 Muffler assembly 1 62A2 303043040 Washer 1
22 303030111 Nut M8 2 62A3 9534960101 Split cotter 1
23 303020382 Bolt M6X12 2 63 303020444
Hexagon Head Flange
Bolt M6X12
2
24 303071503 Wind deflector 1 64 303020513 T-Bolt 1
25 303010323 Carburetor stud 2 65 303030112
Hexagon flange nut with
teeth
1
26 9221960102 Fairwater 1 66 9230960101 Plunger arm 1
27 9245960107 Seal gasket 1 67 9332960101
Speed regulating tension
spring
1
28 9535960101 Thermal baffle 1 68 9013960102 Choke putter 1
29 9245960108 Seal gasket 1 69 9332960102 Throttle tension spring 1
30 9568960701 carburetor assy 1 70 9563960701 Crankshaft box body 1
31 9245960102 Air filter washer 1 71 9246960101 Oil Seal 1
32 303071505 Air filter baffle 1 72 9565960701 Igniter assembly 1
33 9245960102 Air filter washer 1 73 303020643 Bolt M6x16 1
34 9170960100 Air filter holder 1 74 9221960701 Flywheel side shell 1
35 303030112 Self-locking nut 2 75 303020490 Bolt M6x25 2
36 9245960704 Cylinder head gasket 1 76 9152960702
Flywheel housing
assembly
1
37 9140960102 Location pin 2 77 9414960101 Fan 1
38 9013960101 Push Rod 2 78 9194960101 Passive plate 1
39 9536960101 Valve lifter 2 79 303020511 Nut M14X1.5 1
40 9113960101 Intake valve 1 80 9226960701 Starter fan cover 1
41 9113960102 Exhaust valve 1 81 9528960101 Starter assembly 1
42 9564960701 Piston ring assembly 1 82 303020515 Bolt M6X8 4
43 9146960501 Gudgeon pin circlip 2 83 303020382 Bolt M6x12 4
44 9140960701 Piston pin 1
