Powersmart DB7279 - Page 33

33
Item Stock # Description Qty
Item Stock # Description
Q
ty
1 303020245 Flange Screw M8x14 6 30 303180702A Impeller 1
2 303070234 Bearing Housing 2 31 303123006
elastic cylindrical pin
φ6×35
2
3 203060013 Plastic Bearings 2 32 303020166
Square Neck Bolt
M8X18
4
4 203060012 Spacer 8 33 303070197
Skid Shoe（Black)
2
5 303180409 Auger Assembly R 2 34 303030077
Hex Flange Washer nut
M8
4
6 203050108 Spacer 1 4 35 303181008
24" Auger Housing
Assembly (186C red)
1
7 203050109 Spacer 2 8 36 303030087
Hex Flange Washer nut
M8
2
8 302130005 Reinforced Seal 2 37 203050057 Clean-out Tool 1
9 303090031 Worn Gear Case R 1 38 303070170 Clean-out Tool Bracket 2
10 303020142
Bolt M8x10
2 39 303020213 Screw 2
11 303060055 Flange Bushing 2 40 303042078 Flat washer 2
12 303090033 Worm Gear 1 41 303020154
Square Neck Bolt
M8X40
1
13 303110022 woodruff Key 5x7.5x19 1 42 303070190 Idler Arm 1
14 303070260 Seal 1 43 303042039 Flat washer 1
15 303090032 Worn Gear Case L 1 44 303160197
Bushing
1
16 303020489 Screw M6x18 6 45 303210001 Tension Pully Assembly 1
17 303160370 24 inch Auger Axle 1 46 303030077
Flange Nylon Locknut
M8
1
18 303100030 6001Z bearing 1 47 303030059 Locknut M10 1
19 303100035 6904Z bearing 1 48 303130070 Extension Spring 1
20 303070179 washer 1 49 303160128 Gasket set 2
21 303100039 51104 bearing 1 50 303043021 gasket Φ20×Φ32×2.5 1
22 302130002 gasket 1 51 303100040 UC204 Ball Bearing 1
23 303160314 worm 1 52 303070233 Keeper 1
24 303160355 Shear pin Φ6 4 53 303030077
Hex Flange Washer nut
M8
3
25 303180410
New Single-blade Auger
Assembly L color for
black)
2 54 303160128
Gasket set
1
26 303030032
Locknut M6
4 55 303160153 Big Pulley 1
27 303030077
Hex Flange Washer nut
M8
4 56 303110014 flat key 1
28 303070936
24" Shave (186C red)
1 57 303042005 Flat washer 1
