KNOWING YOUR BRUSH CUTTER
Please use the illustration below to familiarize yourself with the location and function of the components
that control of your brush cutter.
Unpacking
Unpack the blower and all its parts, and compare against the list below. Do not discard the carton or
any packaging materials. Please call 1-800-791-9458 or E-mail us at support@amerisuninc.com if any
parts are damaged or missing.
Including:
Brush cutter /Trimmer head/Blade/Blade shield/Handle/Shoulder harness /S3
、
S4 Hex key/Spark plug
wrench/Oiler /User manual
1
Blade
9
Purge Bulb
2
Blade Shield
10
Fuel Tank Lid
3
Shaft
11
Fuel Tank
4
Connector Cover
12
Air Cleaner Cover
5
D-Handle
13
Choke
6
On/Off Switch
14
Starter Handle
7 Safety Lever 15 Cut-off Knife
8
Throttle Trigger
16
Trimmer head
Fig.1
