3
CONTENTS
Technical data…...………………………………………………………... 3
Introduction………………………………………………………………. 4
Safety information…….………………………………………………... 4
General safety procedures ……....……………………………………… 5
Important safety instructions……………………………………………. 6
Knowing your generator………………………………………………… 7
Generator preparation…………………………………………………... 8
Step 1 Setup wheel kit…………………………………………. 8
Step 2 Add oil…………………………………………………… 8
Step 3 Add gasoline……………………………………………… 9
Step 4 Ground the generator……………………………………. 10
Step 5 Connect the battery…………………………………… 10
Starting the generator………....………………………………………… 11
Stopping the generator…………………………………………………. 13
Using the generator……………………………………………………... 13
Maintenance……………………………………………………………... 15
Storage & transport procedures…………………………………………. 20
Troubleshooting…………………………………………………………. 20
Wiring diagram…………………………………………………………. 21
Exploded view & parts list……………………………………………… 22
Warranty………………………………………………………………… 26
TECHNICAL DATA
7500W Generator Model # PS48
Engine type: 4 stroke, OHV, single cylinder with forced air cooling system
Spark plug: F6TC
Spark plug gap: 0.7-0.8 mm (0.028-0.031 in)
Spark plug torque: 1/2-3/4 turn after gasket contacts base or 15 ft.lb
Displacement: 420 cc
Fuel tank capacity: 7.4 gallons / 87 octane minimum
Oil capacity: 37 fl.oz
Lubrication system: Splash lubrication
Rated wattage: 7000W
Surge wattage: 7500W
Rated voltage: 120V/ 240V
Rated amperage: 58.3A/29.2A
Frequency: 60Hz
Phase: Single
Battery: 12VDC, 14Ah
Dimensions (L x W x H): 29.1x21.9x24.4 inches
Run time on 50% load: 9.5 hours
Noise rating: 78 dB at 23 feet
Weight: 206 lb.
