Powersmart PS76138A - Parts List

19
PARTS LIST
Item Stock# Description Qty. Item Stock# Description Qty.
1 PS76138A-001
screw with washer
M4×14
5 31 PS76138A-031 Lower guard 1
2 PS76138A-002
Spindle lock cap
assembly
1 32 PS76138A-032 Baffle 1
3 PS76138A-003
Spinding lock
spring
1 33 PS76138A-033 Inner flange 1
4 PS76138A-004 Gear box cover 1 34 PS76138A-034 TCT blade φ115 1
5 PS76138A-005
Dustproof paper
pad
1 35 PS76138A-035 Blade fixed screw 1
6 PS76138A-006
Clamp
Spring(φ4×φ0.8)
1 36 PS76138A-036 Outer flange 1
7 PS76138A-007
Square neck bolt
M6×26
2 37 PS76138A-037
Screw with washer
ST4.2×12
2
8 PS76138A-008 Bearing 698 1 38 PS76138A-038 Lever for lower guard 1
9 PS76138A-009 Spiral bevel gears 1 39 PS76138A-039 Screw for reset spring 1
10 PS76138A-010 Steel ballφ3 3 40 PS76138A-040 Reset spring 1
11 PS76138A-011 Gear shaft 1 41 PS76138A-041 Screw ST4×14 4
12 PS76138A-012 Bearing 607-2RS 4 42 PS76138A-042 Gear for connecting rod 1
13 PS76138A-013 Intermediate shaft 1 43 PS76138A-043 O-ring 1
14 PS76138A-014 Intermediate gear 1 44 PS76138A-044 Bearing 609-2RS 1
15 PS76138A-015
Circlip for shaft
D9
2 45 PS76138A-045 Circlip for hole D24 1
16 PS76138A-016
Circlip for shaft
D8
1 46 PS76138A-046 Bearing 606-2Z 1
17 PS76138A-017 Pinion 1 47 PS76138A-047 Connecting sleeve 1
18 PS76138A-018 Separation sleeve 1 48 PS76138A-048
screw with washer
M4×8
2
19 PS76138A-019
Circlip for hole
D20
1 49 PS76138A-049 Motor support 1
20 PS76138A-020 Bearing 699 1 50 PS76138A-050 Switch self-locking cap 1
21 PS76138A-021 Connecting tube B 1 51 PS76138A-051 Right housing 1
22 PS76138A-022 Corrugated tube 1 52 PS76138A-052 Screw ST2.9×14 6
23 PS76138A-023
Connecting tube
D
1 53 PS76138A-053 Spinding lock spring 2
24 PS76138A-024 Gear box 1 54 PS76138A-054
rightfront dustproof
window
1
25 PS76138A-025 Spindle shaft 1 55 PS76138A-055
steel wire for front
window
2
26 PS76138A-026 Upper guard 1 56 PS76138A-056
rightrear dustproof
window
1
27 PS76138A-027
Screw with
washer ST4.2×12
2 57 PS76138A-057
steel wire for rear
window
2
28 PS76138A-028 Screw M4×12 1 58 PS76138A-058 hardware pine 1
29 PS76138A-029
Rubber block for
lower guard
1 59 PS76138A-059 PCB board 1
30 PS76138A-030
Screw M5 for
rubber block
1 60 PS76138A-060 Motor 1
