Install the Concealed Hinge (not included)
7. Follow the hinge manufacturer's instructions for installing and
positioning the hinge-mounting plates into the cabinet.
Figure 8
GENERAL MAINTENANCE
WARNING
When servicing, use only identical replacement parts. Use of any
other parts may create a hazard or cause product damage. To
ensure safety and reliability, all repairs should be performed by a
qualied servicetechnician.
WARNING
Keep the Concealed Hinge Jig dry, clean, and free from oil and
grease. Always use a clean cloth when cleaning. Never use brake
uids, gasoline, petroleum based products or any strong solvent to
clean the Concealed Hinge Jig. Chemicals can damage, weaken or
destroy plastic which may result in serious personalinjury.
