PowerTec PL1252 - PARTS LIST

1 PL1250001 Pan Head Screw M8*16 4
2 PL1251001 Portable Sheath 2
3 PL1251002 Left Cap 1
4 PL1251003 Roller Ø20×2.0T×389L 1
5 PL1251004 Right Cap 1
6 PL1250004.6 Crank arm 1
7 PL1250004.5 Handle 1
8 PL1250004.4 Handle Shaft 1
9 PL1250004.3 Handle Cap 1
10 PL1250004.1 Plug 1
11 PL1251005 Socket Head Screw M5*20 1
12 PL1251006 Washer Ø5 1
13 PL1251007 Washer Ø5×Ø14×0.8t 2
14 PL1250012 Tapping Screw ST4.8×10L 4
15 PL1251009 Dust Hood 1
16 PL1251010 Socket Head Screw M5*16 2
17 PL1251012 Dust Chute 1
18 PL1250041 Belt Guard 1
19 PL1251008 Carriage Frame 1
20 PL1250064 Spring 1
21 PL1250065 Cutterhead Lock plate 1
22 PL1250066 Spacer 1
23 PL1250067 Socket Head Screw M5*16 1
24 PL1251014 Hex Bolt M8*20 1
25 PL1251015 Flat washer Ø8 1
26 PL1251016 Spacer 1
27 PL1251017 pointer 1
28 PL1251018 Flat washer Ø3 2
29 PL1251019 Cross head screw M3*6 2
30 PL1251020 Cross head screw M5*8 2
31 PL1251021 Spring Washer Ø5 2
32 PL1250048 Serrated washer Ø5.3*Ø10 2
33 PL1251022 Gearbox Cover 1
34 PL1251023 Socket Head Screw M5*12 17
35 PL1250088 Elevating nut(L.H.) 1
36 PL1250090 Flat washer Ø6.3*15*2T 4
37 PL1250040 Set Screw M5*10 1
38 PL1250039 Cord Clamp UC-1.5 1
39 PL1250038 Cross head screw M5*10 1
40 PL1250091 Elevating nut(R.H.) 1
41 PL1250080 Extend ret ring Ø15.7 3
42 PL1250021 Sprocket 4
43 PL1251024 Spring(infeed) 2
44 PL1251025 Outfeed Roller 1
45 PL1251026 Spring(outfeed) 2
46 PL1251027 Bearing Block 4
47 PL1251028 Retainer 4
48 PL1251029 Infeed Roller 1
49 PL1250081 Chain #410-26 2
50 PL1251030 Guide 2
51 PL1251031 Socket Head Screw M5*10 8
52 PL1251032 Elevating Screw(R.H.) 1
53 PL1251033 Platen 1
54 PL1250093 Elevating Screw(L.H.) 1
55 PL1251034 Flat washer Ø6 1
56 PL1250086 Socket Head Screw M6*10 1
57 PL1250092 Column 3
57-1 PL1250092.1 Subsidiary Column 1
58 PL1250100 Hex nut M12 4
59 PL1251035 Base 1
60 PL1250102 Bearing 6000ZZ 2
61 PL1250105 Spacer 2
62 PL1250103 Retainer 2
63 PL1251036 Pan head Screw M5*12 4
64 PL1250109 Socket Head Screw M4*12 2
65 PL1250108 Spring Washer Ø4 2
66 PL1250107 Flat washer Ø4 2
67 PL1250106 Gear 4
68 PL1251037 Extend table ass. 2
69 PL1251038 Adjust Screw 4
70 PL1251039 Hex nut M10 4
71 PL1250099 Hex nut M6 4
72 PL1250098 Hex Bolt M6*20 4
73 PL1251040 Side Cover 2
74 PL1250122 Scale 22x181 1
75 PL1250117 Support 2
76 PL1251041 Shaft 1
77 PL1250120 Extend ret ring Ø10 2
78 PL1250125 Magnet 2
79 PL1250126 Hex wrench M4×130×70 1
80 PL1250062 Belt 135J6 1
81 PL1251042 Hex nut M16 1
82 PL1250061 Pulley 1
83 PL1251043 Bearing Cover 1
84 PL1251044 Bearing 6204 1
85 PL1251045 Bearing Seat 1
86 PL1251046 Cutterhead 1
87 PL1250056 Key A5*12 1
88 PL1250053 Blade 2
89 PL1250052 Gib 2
90 PL1250057 Pan head Screw M6*16 12
91 PL1250026 Shaft 1
92 PL1250027 Gear 70T 1
93 PL1250025 Bearing 6002-2Z 1
94 PL1250022 Spacer 1
95 PL1250023 Socket Head Screw M5X30 1
96 PL1250024 Outside Cover 1
97 PL1250019 Socket Head Screw M5*35 4
98 PL1251048 Socket Head Screw M5*27 2
99 PL1250031 Spacer B 4
100 PL1251049 Washer Ø8xØ14x0.1 2
101 PL1250029 Gear 52T+12T 1
102 PL1250028 Gear 58T+12T 1
103 PL1250030 Bushing 5
104 PL1250032 Pinion 1
105 PL1250034 Spacer A 1
106 PL1250035 Inside Cover 1
107 PL1250033 Bearing 6203-2Z 1
108 PL1251051 Motor Pulley 1
109 PL1251052 Motor 1
110 PL1250068.2 Sponge 140×60×90 1
111 PL1250016 Sponge 320*10*8 3.5
112 PL1250089 Socket Head Screw M6*P1*16L 4
113 PL1251053 spring 1
12-1/2" THICKNESS PLANER PARTS LIST
13
Key No. Part No. Description Specication Qty Key No. Part No. Description Specication Qty
