PowerTec PT3200i - Page 16

16.
www.powertec.net.nz
PT3200i
3000W DIGITAL
INVERTER GENERATOR
INITIAL OIL FILL
/
NOTICE
Engine oil must be added when the is on a
flat, level surface, or an inaccurate reading may result.
Do not overfill. If the engine is overfilled with oil, it can
cause serious engine damage.
1.
Loosen the screw and remove the engine oil fill/
drain plug service panel to access the oil fill/drain
plug (see Figure 1)
1:
2.
Clean the area around the oil fill/drain plug and
remove plug (See Figure 2).
2:
3.
Using the supplied funnel pour the
oil into
the engine (see Figure 3).
3: Funnel
4.
Do not overfill, if oil level is too high, oil will drain
out through the fill plug. See correct oil level in
Figure 4.
4: Level
BEFORE AOOING ENGINE OIL, REVIEW
SAFETY SECTION
