PT3200i EXPLODED VIEW
469.2420.002V.04.00
6178.0500.00.04
Muffler shield
Clip nut
7
469.6950.002V.00.01
Control harness
469.2470.001V.00.00
Inverter
148.2000.001V.00.01
Starting handle
469.3370.001V.00.99
Control panel
469.5596.004V.A6.00
Right exterior cover
469.2222.002V.04.00
Right housing assembly
467.4789.001V.00.00
Step bolt
3
469.4259.001V.A6.00
Spark plug cover plate
5
17
16
15
2
2
2
2
2
2
2
14
1
12
13
13
