ABOUT THE REGULATOR
1.
Safety Information
•
Read all of the instructions in the manual before installation.
•
DO NOT disassemble or attempt to repair the regulator.
•
Disconnect the solar panel before installing or moving the regulator.
•
Power connections must remain tight to avoid excessive heating from a loose
connection.
•
Only charge 12V batteries that comply with the parameters of regulator.
•
Battery connection may be wired to one battery or a battery bank.
2. Overview
The 12V/10A regulator is a PWM charge regulator with USB output that uses the
most advanced digital technique. Regulator features as follows:
•
Support 3 charging options: AGM, Gel &FIooded lead acid battery
•
Battery status LED indicator indicates battery situation
•
The USB will provide power supply that can charge electronic equipment
•
Battery type and load output can be set via button
•
Extensive Electronic protection
3. Regulator unit
1. MENU KEY
2. PAGE UP 3. PAGE DOWN/OPERATION
4. LCD DISPLAY 5. USB CONNECTIONS
