Inputs:
- Signal IN (IN4) Æ No function
Æ Line interface (wire E)
Æ Ignition control
Æ Another event
- Input 1 (IN1/PTT): Æ PTT external
Æ Another event
- Input 2 (IN2/AUX): Æ External AUX (disconnect the call and
begin a private hook call)
Æ Another event
- Input 3 (IN3/HANG): Æ External HANG (HANG UP)
Æ Another event
Outputs:
- Relay out (OUT1) Æ No function
Æ External horn relay
Æ Mute
Æ Another event
- Signal out (OUT2): Æ No function
Æ Line interface (wire M)
Æ Another event
