Solution Tank: The solution tank is located under the lid,
at the front of the machine, with the filling-funnel M1 in an
accessible position for easy re-filling.
WARNING: Always switch off and unplug the machine before
filling the solution tank.
Note: Always empty the dirty water collection tank, as described
in the next paragraph, before refilling the tank with the diluted
detergent solution. The solution tank has a maximum capacity
of 8 gallons (30 liters). Always use the products and the
dilution quantities recommended by the seller. Always use
low foam detergents. Use defoamer if excess foam develops.
Remove hose from vac intake and pick up defoamer directly
into the recovery tank.
Water collection tank: The dirty water collection tank should
be emptied, preferably each time after use, so that the dirt
does not settle there. To do this, remove the plug of the drain
hose M2, which is kept in position by a simple spring clip, and
empty dirty water into the proper drain conforming to local
regulations.
Squeegee: The squeegee has the final task of completing the
drying of the floor and it is very important for it to be in the
correct position. Lower the squeegee to the working position
by depressing pedal M3 as shown. Adjust the position of the
squeegee by means of the knobs M4 so that the black rubber
bar is about
1
⁄
32
” (the thickness of a business card)
from the floor. The squeegee behind this is in para rubber
and must press on the floor with a certain amount of force.
After the first few hours the squeegee adjusts itself
to the correct angle and drying becomes even better.
Squeegee pressure is adjusted by knob M14.
- 5 -
GENERAL OPERATION
