PPE Stage 3 - Maintenance Instructions; Adjustment to Eliminate End-Play

Stage3 Tie Rod Assemblies
Tie Rod Ball Stud
Lock nut
End Cap
1 1/8” Jam nut
Inner ats (5/8”)
Zerk tting (2011+ only)
Inner face
Tie Rod length
Grease tting
Adjustment to
eliminate end-play
Remove set screws (2)
Use pliers to
secure here -------------------
Tighten inner face --------
Apply Loctite
to set screws
Reinstall set screws
Maintenance
Instructions
+
