PPI Zenex - Mechanical Installation Precautions; Controller Outer Dimensions; Panel Cutout and Spacing Requirements

28
Figure 10.5
Mounting Output-2 Module
Figure 10.6
Mounting Output-3 Module
Output
Module
Projections
P
P
I
Plug & Socket
Connector
Slots
CPU Board
Front Label
Upside-down
zenex
P
I
P
Plug & Socket
Connector
Projected
Parts
Slots
Output
Module
Power Supply Board
Front Label Upright
zenex
User Manual
zenex
