PPI Zenex - Output Module Jumper Settings (96 x96)

39
Output-2 & 3 Jumper Settings Table 2.2
OUTPUT-2 & 3 : Jumper Settings
Besides the parameter settings, the Output-2 & 3 configuration requires jumper settings selections as shown in the Table 2.2
below.
Figure 2.2 illustrates mounting of Output Modules.
1 2 3
1 2 3
Relay
SSR
Output Type Jumper Setting - BJumper Setting - A
1 2 3
1 2 3
Figure 2.2
User Manual
zenex96
Mounting / Un-Mountion of Modules
The Figure 2.2 Illustrates how to mount output-2 module, respectively. Notice the orientation of the controller & a few
identifying components shown in figure to help locate the plugs for the modules.
Output 2 A & B
Jumper Settings
B
1
3
2
A
Display
CPU Board
Keys
}
Mounting Output Modules
1
3
2
